Z-Track (PVDF) is a pressure track closure made from a high performance polyvinylidene fluoride extrusion compound. The PVDF material, recognized commercially under the trade name Kynar, has best abrasion and chemical resistance, making it an ideal choice for heavy-duty applications. Z-Track (PVDF) can be combined or sewn to a heat reflective material and utilizes an arrowhead-and-channel inter-locking closure system. This closure system is used by the aerospace and automotive industries due to its strong, durable properties. Z-Track (PVDF) is clear in color, but can be customized to your color preference upon request. Z-Track (PVDF) can withstand extremely low and high temperature environments of -33°F to 302°F (-36°C to 150°C).
| Chemical Resistance | Excellent |
|---|---|
| Flammability | UL94 V-0 |
| Fluid Resistance | Best |
| Abrasion Resistance | Best |
| Shelf Life | 60 months |
| Minimum Operating Temperature | -32.8 ° F (-36 ° C ) |
| Maximum Operating Temperature | 302 ° F (150 ° C ) |
| Flexibility | Good |
| Material Color | Clear |
|---|
Specifications subject to change without notice. All statements and technical information contained herein are based on tests we believe to be reliable, but the accuracy or completeness is not guaranteed under all circumstances. Before using Zippertubing® products, the user shall determine suitability for the intended use, and user assumes all responsibility for improper selection. Published attenuation values of Zippertubing® shielding have been verified by laboratory testing of the respective shielding materials. Actual installed attenuation values may differ due to installation techniques and final assembly operation parameters which are beyond the control of Zippertubing®. Actual attenuation values can only be determined by the end user testing the completed assembly. U.S. and International Patents and patents pending. © 2021 The Zippertubing® Company, Chandler, Arizona.
