Zip-On® (PVDF)

A wrap-around cable protection and management solution utilizing a polyvinylidene fluoride (PVDF) material that has best chemical, UV and abrasion resistance.
  • PVDF material is highly resistant to chemicals, UV and abrasion
  • Z-Track interlocking closure provides secure seal around wires and cables
  • Holds up to a wide operational temperature range of -33°F to 302°F (-36°C to 150°C)

Shape of Installation: Round
Closure: Z-Track (FEP)
Cable Diameter:

Details

Specifications

Materials

Print Datasheet


Details

Zip-On® (PVDF) bundles and protects wires and cables from chemicals, UV and abrasion.

Zip-On® (PVDF) is a semitransparent white, wrap-around cable management solution made from UL-rated, PVDF film jacketing. Recognized commercially under the trade name Kynar, Zip-On® (PVDF) offers good flexibility and best resistance to chemicals, UV and abrasion, making it an ideal choice to protect wires and cables that are exposed to rugged conditions.

Zip-On® (PVDF) utilizes a Z-Track closure system. This patented arrowhead-and-channel interlock-design closure is one of the strongest pressure track closures Zippertubing® offers; it provides a secure seal to keep fluids, dust and debris from damaging the components inside. Z-Track can be installed with the ZTZ-SP Plier tool, which is ideal for longer cable runs, to reduce installation fatigue. To learn how to install Z-Track, check out our live demo here.

The PVDF jacketing holds up to a wide temperature range of -33°F to 302°F (-36°C to 150°C) and can be RF welded to other polymer tracks or films. Zip-On® (PVDF) is offered for diameters ranging from 0.375” to 4”, with custom sizes available upon request.


Benefits

  • Highly resistant to chemicals, UV and abrasion
  • Can be RF welded to other polymer tracks or films
  • Engineered for diameters up to 4”, with custom sizes available up request

Features

  • Custom extrusion pressure track closure with a strong mechanical inter-locking system
  • UL rated, polyvinylidene fluoride (PVDF) jacketing
  • Operational temperature range of -33°F to 302°F (-36°C to 150°C)

Specifications

Flammability UL94 V-0
Fluid Resistance Best
RoHS Compliant
Shelf Life 60 months
Abrasion Resistance Best
Minimum Operating Temperature -32.8 ° F (-36 ° C )
Maximum Operating Temperature 302 ° F (150 ° C )
Flexibility Good

Available Attributes

Please contact us for custom needs. We have a solution for you!

Shape of Installation Round
Closure Z-Track (FEP)
Cable Diameter 0.375" (3/8)
0.5" (1/2)
0.625" (5/8)
0.75" (3/4)
0.875" (7/8)
1.0"
1.125" (1 1/8)
1.25" (1 1/4)
1.375" (1 3/8)
1.5" (1 1/2)
1.625" (1 5/8)
1.75" (1 3/4)
1.875" (1 7/8)
2.0"
2.125" (2 1/8)
2.25" (2 1/4)
2.375" (2 3/8)
2.5" (2 1/2)
2.625" (2 5/8)
2.75" (2 3/4)
3.0"
3.125" (3 1/8)
3.25" (3 1/4)
3.375" (3 3/8)
3.5" (3 1/2)
3.75" (3 3/4)
3.875" (3 7/8)
4.0"
Material Color Clear

Materials

Z-Track (FEP)

Flammability UL94 V-0
RoHS Compliant
Shelf Life 60 months
Abrasion Resistance Best
Minimum Operating Temperature -300 ° F (-184 ° C )
Maximum Operating Temperature 400 ° F (204 ° C )
