Tape (Specialty Surface) with Drawing Number: 5006

Tape (Specialty Surface)

Specification No. 5006

Thin, Highly Flexible, Acrylic Transfer Adhesive

  • Hi-Temp Transfer Adhesive
  • Extremely Thin Closure
  • Custom Widths Available
  • Simple Thumb Pressure Closure (Tooless)

Raw materials are not sold separately, please contact the sales department for any special requirements.

Material Specifications

Available Attributes

Material Color Clear

Tape (Specialty Surface)

Color Clear
Shelf Life 12 months, unbonded (Zippertubing)
Humidity Resistance Excellent
Release Liner Polycoated Paper Liner
Adhesion (72 hr) 140 oz-in. (to steel) 136 oz-in. (to Polyproylene)
Humidity Resistance Excellent
Adhesive Acrylic (fiber reinforced)
Material Thickness 0.005"
Humidity Resistance Excellent
RoHS Compliant
Temperature -40° to +93°C Days/Weeks 149°C Minutes/Hours
Shear Strength >200 grams @ 200 C (1/2" overlap)

Specifications subject to change without notice. All statements and technical information contained herein are based on tests we believe to be reliable, but the accuracy or completeness is not guaranteed under all circumstances. Before using Zippertubing® products, the user shall determine suitability for the intended use, and user assumes all responsibility for improper selection. Published attenuation values of Zippertubing® shielding have been verified by laboratory testing of the respective shielding materials. Actual installed attenuation values may differ due to installation techniques and final assembly operation parameters which are beyond the control of Zippertubing®. Actual attenuation values can only be determined by the end user testing the completed assembly. U.S. and International Patents and patents pending. © 2019 The Zippertubing® Company, Chandler, Arizona.

A thin high temperature Acrylic transfer adhesive used to create permanent jacket closures on contaminated low surface energy plastic as well as metal materials. This specially formulated transfer adhesive and will withstand both low and high temperature extremes and bonds well to oil contaminated surfaces. When properly sealed and heat set the adhesive creates a strong semi-permanent bond that cannot be reopened easily. Attempting to remove and reset this adhesive after initial placement will destroy the strength of the material.
