Cross-linked Polyolefin Copolymer

Re-jacket, seal, and protect damaged cables and/or cable joints.

Material Specification No. 6013

Raw materials are not sold separately, please contact the sales department for any special requirements.

Details

An adhesive lined electrical insulation sleeve that will shrink to a pre-determined size upon the application of heat and provide a watertight seal.


Specifications

Cross-linked Polyolefin Copolymer

Dielectric Strength >12kV/mm
Fluid Resistance Excellent
Fungicide Pass Rate 1
Longitudinal Shrinkage <10%
Water Absorption 0.5% maximum
Elongation >350%
Material Thickness 0.048" - 0.050"
Shrink-Ratio 3:1
Minimum Operating Temperature -31 ° F (-35 ° C )
Maximum Operating Temperature 212 ° F (100 ° C )
Tensile Strength >2460 psi.

Available Attributes

Exterior Material Cross-linked Polyolefin Copolymer
Material Color Black

Specifications subject to change without notice. All statements and technical information contained herein are based on tests we believe to be reliable, but the accuracy or completeness is not guaranteed under all circumstances. Before using Zippertubing® products, the user shall determine suitability for the intended use, and user assumes all responsibility for improper selection. Published attenuation values of Zippertubing® shielding have been verified by laboratory testing of the respective shielding materials. Actual installed attenuation values may differ due to installation techniques and final assembly operation parameters which are beyond the control of Zippertubing®. Actual attenuation values can only be determined by the end user testing the completed assembly. U.S. and International Patents and patents pending. © 2021 The Zippertubing® Company, Chandler, Arizona.
